NIKKON LEDXION S536 High-Performance LED Street Lantern 150W to 210W Excellent Marine-Grade Roadway Light with ILCS® Smart Control and IP66 Waterproofing

Description

NIKKON LEDXION S536 High-Performance LED Street Lantern 150W to 210W Excellent Marine-Grade Roadway Light with ILCS® Smart Control and IP66 Waterproofing

The NIKKON LEDXION S536 STREET LANTERN is a premier, industrial-grade lighting solution specifically engineered for large-scale infrastructure and challenging outdoor environments.

This robust street Lantern series offers a powerful range of wattage configurations, including 150W, 170W, 180W, 190W, 200W, and 210W, delivering a massive typical luminous flux reaching up to 25,570 lumens.

This street Lantern Designed for maximum longevity, it features a housing crafted from marine-grade non-corrosive aluminium, finished in a professional Dark Gray (Akzo Nobel RAL7012) powder coating to resist environmental degradation.

Technically advanced, the street Lantern S536 series utilizes a Ceramic (Alumina Substrate) PCB with Silver (Ag) conductors and WAGO 2060 Series SMD connectors for superior thermal management and high-level electrical reliability.

It provides exceptional visibility through a 95% transparency tempered glass optical cover and offers multiple color temperature options: 3000K Warm White, 4000K Neutral White, and 5000K Cool White.

A key advantage for modern infrastructure is its compatibility with the Intelligent Light Control System (ILCS®), facilitating smart city energy management.

The unit is built to withstand extreme conditions with an IP66 ingress protection rating and IK08 impact resistance.

Additionally, it is reinforced by 10KV/20KA surge protection, ensuring stable performance in temperatures from -30°C to +45°C.

Whether for motorways, expressways, or municipal areas, the street Lantern NIKKON S536 is a sustainable, low-maintenance choice for professional roadway illumination

Product Features :

• High-Power Performance: Available in six wattage options: 150W, 170W, 180W, 190W, 200W, and 210W.

• Exceptional Luminous Flux: Delivers typical flux from 20,110lm up to 25,570lm (tested at 5000K CCT).

• Smart City Ready: Features the ILCS® (Intelligent Light Control System) for advanced smart monitoring and energy management.

• Marine-Grade Build: Constructed from marine-grade non-corrosive aluminium, ideal for coastal or industrial environments.

• Advanced Module Technology: Utilizes a Ceramic (Alumina Substrate) PCB with Silver Conductor (Ag) traces for optimal thermal dissipation.

• Extreme Longevity: Rated for a service life of 100,000 hours (L70) at 25°C.

• Rugged Environmental Protection: Fully rated IP66 for dust/water resistance and IK08 for high impact resistance.

• Precision Optics: Features 95% transparency tempered glass with Type 1, Type 2, or Type 3 light distribution options.

• Robust Surge Protection: Integrated 10KV/20KA surge protection to safeguard electronics from power spikes.

• Broad Operating Range: Reliable performance in temperatures ranging from -30°C to +45°C.

• Customizable Controls: Supports optional Time Control, 1-10V Dimming, NEMA Photocell, and Full Programmable drivers.

• Versatile Application: Specifically designed for rural/urban roads, expressways, car parks, roundabouts, motorways, and municipal areas
