Description
REDLABEL Inline Duct Fan 200V-50Hz Dave Series – Low Noise Commercial Ventilation Fan
The REDLABEL Dave Series Inline Duct Fan is a professional-grade solution engineered for superior, high-airflow ventilation within duct systems.
The key feature of this series is its dual-speed functionality, allowing users to switch between high-power modes for rapid air exchange and lower-power modes for continuous, energy-efficient background ventilation.
Models range from the compact Dave-100-1G (up to 198 m³/h) to the robust Dave-200-1G (up to 1200 m³/h), making them versatile for use in small apartments, grow tents, and large commercial spaces (up to 78 m²).
Despite their powerful output, the Dave Series fans are designed for low-noise operation, with the smaller models achieving noise levels as quiet as 25 dB.
This balance of performance and acoustics makes them an ideal choice where noise reduction is critical.
Built for durability and easy installation within your existing ductwork, the REDLABEL Inline Duct Fan is the definitive choice for professionals seeking a reliable, high-performance, and dual-function system for maintaining optimal indoor air quality.
Specification :
| Parameter | Dave-200-1G | Dave-150-1G | Dave-100-1G |
| Voltage | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz |
| Air Flow (m³/h) | 1200 / 890 | 540 / 360 | 198 / 168 |
| Power (W) | 110 | 70 | 60 |
| Air Pressure (Pa) | 350 / 280 | 300 / 250 | 180 / 130 |
| Noise (dB) | 50 / 45 | 35 / 30 | 30 / 25 |
| Size Ø (mm) | 200 | 150 / 160 | 100 / 125 |
| Area of Use (m²) | 34–78 | 18–36 | 8–16 |
| Size (W × D × H mm) | 237 × 304 × 235 | 214 × 293 × 211 | 214 × 300 × 182 |
| Weight (kg) | 3.1 | 2.2 | 1.8 |
Dimension :
Installation Guide
