VICTOR Vibration Meter VC63D Series – Accurate Displacement, Velocity, & Acceleration Meter
The VICTOR Vibration Meter VC63D Series is a professional-grade instrument designed for accurate and reliable machinery diagnostics.
This versatile device measures three key parameters of vibration: displacement, velocity, and acceleration. Its impressive range and high resolution allow technicians to easily identify imbalances, misalignments, and bearing faults in industrial equipment, motors, and fans, helping to prevent costly failures before they occur.
This vibration analyzer is engineered for precision with an accuracy of ±5% + 2 words. It provides clear readings with an intuitive interface, and it can be used in a wide range of ambient temperatures and humidity levels.
The VC63D features a data retention function that holds the measurement after you release the button, and it automatically shuts down after 5 minutes to conserve power.
Lightweight and portable, the VICTOR VC63D Vibration Meter is the definitive choice for maintenance engineers and technicians who require a durable, efficient, and powerful tool for proactive maintenance and fault detection.
Specification :
| Measuring Range | ||
| Parameter | Range | |
| Vibration Displacement | 1–19999 µm P-P (RMS×2.828) | |
| Vibration Speed (RMS) | 0.1 – 199.9 mm/s RMS | |
| Vibration Acceleration (O-P) | 0.1 – 199.9 m/s² Peak (RMS × 1.414) | |
| Frequency Range | ||
| Parameter | Range | Note |
| Acceleration | 10 Hz – 1 kHz (LO) | 10Hz – 1kHz (LO) 1kHz – 15kHz (HI) |
| Speed | 10 Hz – 500 Hz (LO) | 10Hz – 500Hz (LO) |
| Displacement | 10 Hz – 500 Hz (LO) | 10Hz – 500Hz (LO) |
| General Specification | ||
| Item | Details | |
| Measured Data Type | Lo m/s², Lo mm/s, Lo µm, Hi m/s² | |
| Measurement Accuracy | ±5% ±2 words | |
| Low Voltage Indication | Displays prompt – charging should be done at this time | |
| Data Retention Time | After releasing measurement button, shuts down after 5 minutes | |
| Indication Value Fluctuation | Fluctuation not greater than one resolution | |
| Ambient Temperature | 0 – 40°C | |
| Relative Humidity | ≤80% | |
| Atmospheric Pressure | 75 – 16 kPa | |
