Description
BSLight UFO SMD LED High Bay Light Eco Series 10KV Surge Protection Built-in Cooling Fan (100W / 150W / 200W) Outstanding Performance
Illuminate massive indoor spaces with the exceptional power and thermal engineering of the BSLight UFO SMD LED High Bay Eco Series.
Meticulously developed to tackle the most demanding structural environments, this commercial-grade luminaire serves as the premier choice for large-scale warehouse lighting, high-ceiling factory lighting, indoor stadium lighting, and sprawling distribution centers.
Constructed from a solid aluminum die-casting housing paired with a high-durability polycarbonate diffuser, this high bay is designed to deliver uniform light distribution while standing up to rigorous industrial settings.
The core engineering highlight of the Eco Series is its pioneering thermal management system. Each fixture is built with an integrated cooling fan design powered by a highly reliable DC brushless fan motor.
This advanced setup continuously draws heat away from internal components, enabling the fixture to maintain optimal light levels and achieve an extended operational lifespan of 35,000 hours with minimal maintenance.
Electrical stability is further maximized by an industrial-grade 10KV surge protection system, shielding the unit from sudden voltage spikes and power grid anomalies.
Running smoothly across a wide voltage range of AC85-265V (50/60Hz), this high bay maintains a professional power factor of 0.95 and an ambient operating range from -20°C to 50°C.
Delivering a standard 90° beam angle and an excellent Color Rendering Index (CRI >80), it ensures bright, precise visibility on warehouse floors.
The series offers multiple scalable power outputs to fit your ceiling height: the 100W (15,000 LM) model, the 150W (22,500 LM) variant, or the ultra-powerful 200W (30,000 LM) unit.
For added beam shaping, optional aluminum or polycarbonate shades are available to optimize your layout.
Product Details
- Brand & Product Series : BSLight UFO SMD LED High Bay <<ECO SERIES>_
- Thermal Protection System : Built-in Cooling Fan Design with DC Brushless Motor
- Grid Surge Protection : 10KV Surge Protector Integrated
- Housing & Diffuser Material : Solid Aluminium Die-Casting Casing | Polycarbonate Diffuser
- Primary Applications : Ideal for Warehouse Lighting, Factory Lighting, and Stadium Lighting
- Operational Lifespan : High Brightness & Long Life LED Chips (35,000 Hours Rating)
- Input AC Voltage & Freq. : AC 85 – 265V | 50/60Hz Wide Voltage Driver
- Power Factor (PF) / CRI : PF: 0.95 | Color Rendering Index: CRI > 80
- Beam Angle Spread : 90° Standard Industrial Beam Spread
- Operating Temperature : -20°C ~ 50°C Ambient Capability
- Ingress Protection Level : IP44 Protection Rating
- Optional Add-On Feature : Reflective Shades Available (Dimensions Vary by Wattage Selection)
- Model: BSHB02-100/ECO : 100W | 6500K | 15,000 LM | Size (Ø H): 194 x 93 | Weight: 1.6kg
- Model: BSHB02-150/ECO : 150W | 6500K | 22,500 LM | Size (Ø H): 290 x 96 | Weight: 2.1kg
- Model: BSHB02-200/ECO : 200W | 6500K | 30,000 LM | Size (Ø H): 320 x 97 | Weight: 2.8kg
Common FAQs for BSLight Eco Series UFO LED High Bays
Q1: Why does this industrial UFO high bay light feature an internal cooling fan?
A: High-wattage LED fixtures installed near factory ceilings generate significant heat. The built-in cooling fan uses a long-lasting DC brushless motor to actively push heat away from the LED chips and internal driver circuits. This active thermal management preserves light output efficiency and helps achieve a 35,000-hour lifespan.
Q2: What protection does the 10KV surge protector provide to my electrical installation?
A: Large commercial buildings often experience voltage spikes from lightning strikes or heavy factory machinery cycling on and off. The integrated 10KV surge protection acts as an electrical shield, absorbing these sudden energy spikes to protect the internal electronic components from burning out prematurelly.
Q3: Can this UFO high bay handle voltage fluctuations in areas with unstable power grids?
A: Yes, the Eco Series is equipped with a wide-voltage driver that handles input variations from AC85V all the way up to 265V. This keeps the output light level completely stable and flicker-free, even if your local industrial park experiences temporary voltage drops.
Q4: Are the optional high bay shades required, and what sizes are available?
A: Shades are optional add-ons used to shape the light beam or reduce glare. The dimensions correspond to your fixture wattage: the 100W model uses a $\varnothing380\times156\text{mm}$ shade, the 150W uses a $\varnothing420\times175\text{mm}$ shade, and the larger 200W/250W/300W series uses a $\varnothing467\times165\text{mm}$ shade template.
Q5: Can I mount this high bay light in unconditioned spaces or cold storage facilities?
A: The luminaire is rated to operate reliably within a broad temperature range of $-20^{\circ}\text{C}$ to $50^{\circ}\text{C}$. This thermal tolerance makes it excellent for hot industrial manufacturing zones as well as unheated storage areas or mid-tier cold storage configurations.
